Jaw crusher machine from Gongyi fuwei factory China

FOB Reference Price:Get Latest Price
$1,000.00 - $900,000.00 / Sets | 1 Set/Sets (Min. Order)
Power(W):
depend on the specification
Model Number:
PE/PEX
Lead Time:
Quantity(Sets) 1 - 2 >2
Est. Time(days) 10 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Jaw Crusher
Application:
ore,building,crushing etc,
Motor Type:
AC Motor
Capacity(t/h):
1--400t/h
Place of Origin:
Henan, China (Mainland)
Brand Name:
Fuwei
Dimension(L*W*H):
depend on the specification
Weight:
depend on the specification
Certification:
ISO9001:2008/CE
Warranty:
1 Year
After-sales Service Provided:
Video technical support, Online support, Field maintenance and repair service
Color:
optional
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
standard container,spare parts will be packed in wooden cases
Port
Qingdao, Tianjin, Shanghai
Lead Time :
Quantity(Sets) 1 - 2 >2
Est. Time(days) 10 To be negotiated

Jaw crusher machine from Gongyi fuwei factory China

Product Description



The jaw crusher is widely used in mining, metallurgical industry, building material, highway, railway and chemical industry. The PE series jaw crusher is widely applied in mine, metallurgy, chemical industry, building, highway, water conservancy, and light industry to crush or break various kinds of stones with compressive strength of not more than 350Mpa.
The motor transmits power through belt, drives the moving jaw do periodic motion to the fixed jaw surrounding the eccentric shaft. The angle between toggle plate and moving jaw increases when moving jaw moves up. So the moving jaw closes to the fixed jaw. The stuff will be crushed in this process. The angle of Jaw Crusher between toggle plate and moving jaw decreases when moving jaw moves down; the moving jaw of Jaw Crusher moves away from fixed jaw by the pulling of rod and spring, and the products after crushing will be discharged from the outlet of Jaw Crusher.

Specification of the jaw crusher
Model

Opening Size

(mm)

  Max. Feeding

Size (mm)

Discharge

Size(mm)

Capacity

(t/h)

Power(kw)Dimension(mm)
PE-250×400250×40020020-505-20151430×1310×1340
PE-400×600400 ×60035040-10015-6030-371700×1732×1653
PE-500×750500×75042550-10040-11045-552035×1921×2000
PE-600×900600 ×90048065-16090-18055-752290×2206×2370
PE-750×1060750 ×106063080-140110-32090-1102655×2302×3110
PE-900×1200900×120075095-180220-4501323475×2826×3025
PE-1000×12001000×120085095-190230-5001323800×3166×3045
PE-1200×15001200×15001020150-300400-8002204930×3148×3703
PE-1500×18001500×18001200220-350450-10003555630×3210×4120
PEX-150×250150×25012510-401-35.5896×745×935
PEX-150×750150×75012518-485-16151200×1500×1200
PEX-250×750250×75021025-6015-3022-301667×1545×1020
PEX-250×1000250×100021025-6015-5030-371550×1964×1380
PEX-250×12001200×25021025-6020-6037-452192×1900×1950



















Company Information



 Gongyi Fuwei Heavy Machinery Plant is located in Gongyi city 82kilometers away from zhengzhou city (capital of Henan province) ,we have an office in zhengzhou Zhongyuan Wanda Plaza which is convenient for your visit.



We are engaged in the scientific research , production and sales of energy saving light and heavy machinery and have more than 30years manufacturing experience and have CE certificate and ISO 9001:2008.



Our production lines :Autoclaved Aerated Concrete (AAC) production line, sand production line, cement production line, lime production line and mining production line.



Our main products : Jaw Crusher, hammer crusher, ball mill, sand making machine, flotation machine, rod mill, wet pan mill, dryer ,rotary kiln, brick making machine, nail making machine,charcoal machine.



We can provide you the site visit ,project design, technological process design free of charge before order and installation, commissioning and trainning after order.





FAQ

1.Are you a manufacture ?



Yes,we are a manufacture and founded about 30years .



2.Can you do export by yourself ?



Yes, we have the right to do export by ourself .



3.How can i visit you ?

By air , the nearest airport is Zhengzhou Xinzheng international airport which is in zhengzhou city,Henan province,China

By train, the nearest is zhengzhou train station or East Zhengzhou Train station

We have one office in Zhengzhou city and we can pick you up very easily .
